T1070G5421903, the Suntecc OCuLink 8611 4i Straight Ribbon Cable, is intended for ribbon routing between OCuLink 4i ports. It connects OCuLink SFF-8611 4i, straight to OCuLink SFF-8611 4i, with this construction: Straight connector, ribbon cable. Cataloged in the PCIe 4.0 series, this ribbon version requires attention to the plane of the cable. Mark the routing plane and structural gaps on the assembly drawing.
Installation and variant selection
Ribbon cable does not necessarily mean FPC or FFC and does not establish repeated flexing capability at the plug. Review bending and support against the actual cable construction.
Measure the installed route, including plug bodies and cable turns. Preserve mating and latch access when positioning this OCuLink harness and its supports.
Electrical matching
Match wiring to the board and device documentation, including populated lanes, sideband and power assignments. Define operating conditions for the ordered length and system configuration. Interface shape alone does not establish protocol conversion or verified link rate.
Factory quotation and drawing review
Suntecc assesses drawing-based OEM requirements. For T1070G5421903, send mating connector details, the pin table, installation views, length and quantity. List branch or power-end requirements separately. Length, exit direction and wiring changes are reviewed against this construction before the order configuration is agreed.
